Description

Jet 15″ Floorstanding Drill Press (716250)

The JET JDP-15F, 15” Floor Standing Drill Press. From a full 3-1/8” of spindle travel to the sturdy cast iron head with a poly v-belt drive system, this drill press is designed to perform. This drill press features a long-lasting, built-in LED work light to provide direct lighting while reducing shadows. Another feature includes the one-handed belt-tensioning system and a large 12-1/2″ x 17″ work table which are all CSA Certified.

Features:

• Integrated depth stop makes repetitive drilling quick and easy
• Large cast iron base provides stability
• One-handed belt tensioning allows for rapid speed changes
• Power switch features a safety key and large, paddle-style off button
• Powered by an efficient 3/4HP, 1Ph, 115V TEFC motor and poly-v belt drive system
• Replaceable MDF table insert
• Table edge lip designed to make clamping easy
• Xacta-X laser system easily identifies the drill center

Specifications:

• Assembled Machine Dimensions (L x W x H) (In.): 27 x 17 x 63-1/4
• Chuck Size (In.): 5/8
• Column Diameter (In.): 2-3/4
• Motor Power (HP): 3/4
• Motor Voltage (V.): 115
• Number of Spindle Speeds: 16
• Prewired Voltage (V.): 115
• Prop 65: Cancer and Reproductive Harm
• Spindle Distance to Base (In.): 46-1/2
• Spindle Distance to Table (Max.) (In.): 30-1/2
• Spindle Travel (In.): 3-1/8
• Style (Type): Floor standing Model
• Swing (In.): 15
• Table Size (L x W) (In.): 12-1/2 x 17
• Weight (Lbs.): 172
