• INTELLISAND®Technology:Automatically adjusts conveyor speed based on load
• Prevents gouging, damaging or burning stock
• Provides consistent finish even with varying grain pattern and density
• Greatly increases abrasive planing and dimensioning speed
• Flatness Guarantee:Precision-flattened steel conveyor bed reinforced with four steel cross sections for no “flex” in conveyor, guaranteeing flatness to less than .010″ across the width of the sander
• Abrasive conveyor beltoffers the best grip for raw wood, giving you the ability to accommodate stock that is much shorter or thinner
• Patented Abrasive Attachment Systemeffectively tensions the abrasive wraps, preventing loose abrasive and overlap
• Easiest accessto abrasive fastening system of any drum sander! Extra wide space to access fasteners to eliminate need for special tools
• Self-cooling drumprevents overheating and extends abrasive life
• Tension rollersare adjustable in height and hold down pressure, eliminating snipe
• Excellent dust extractionas dust cover is formed to shape of drum
• Metal, not plastic, is formed to maximize air flow and dust extraction
• Heavy-duty cast iron constructionfor strength, rigidity and reduced vibration
• Mobile baseallows for stand and machine to be to moved easily

Sanding Max. Width:25″
Sanding Min. Length:3-1/2″
Sanding Max. Thickness:6″
Sanding Min. Thickness:1/32″
Dimensions (H x W x D):43″ x 46″ x 31″
Drum (Extruded Aluminum):5″ x 25″
Drum Speed:1,740 RPM
Dust Hood (Steel Hood, Hinged At Back):(2) 4″ Vacuum Ports
Min CFM:1,000 Recommended
Ball Bearing (1″):4 sealed and permanently lubricated
Conveyor Motor:100 in. -lb. torque, direct drive D.C. motor, ranged variable, 0-15 FPM
Drive Motor (TEFC):5hp, 1 Phase
Power Requirements:208-230V, 60Hz; 1 Phase, 30 Amp Service; 3 Phase 20 Amp Service
Shipping Weight:475 lbs.
Shipping Dimensions (L x W x H):50″ x 44-1/2″ x 44-1/2″
