Description
Specifications:
|
Construction: |
Heavy-duty cylindrical lock housing with cast front housing, unified trim plate, and fixed ADA-compliant levers |
|
Locking Device: |
Cylindrical ½” (13 mm) throw latch, floating face plate 2¾” (70 mm) backset (UL listed) |
|
Numeric Keypad: |
Vandal resistant, solid metal pushbuttons |
|
Handing: |
Left Hand or Left Hand Reverse |
|
Finish: |
Antique Brass (05) |
|
Backset: |
2¾” (70 mm) backset |
|
Latch: |
½” (13 mm) throw latch |
|
Minimum Stile Recommended: |
5″ (127 mm) |
|
Strike: |
Standard strike plate; ASA strike plate |
|
Door Preparation: |
Easily installs on wood or metal doors. ASA 161 door preparation with additional through holes. |
|
Door Thickness: |
1⅜” (35 mm) to 2¼” (57 mm)—Pre-assembled to accommodate 1⅝” (41 mm) to 2″ (51 mm) doors |
|
Accessibility Standard: |
Americans with Disabilities Act (ADA) |
|
Durability: |
D.O.D. Compliant 5220.22M for supplemental access control; weather resistant |
|
Fire Rating: |
3-hour UL/ULC fire rating for “A” label doors |
|
Warranty: |
3 years manufacturer warranty |
Downloads:
- Installation Guide
- Spec Sheet
Return Policy:We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact DORMA KABA directly at 1-800-849-8324 or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
