Description
Features & benefits
- Protection-insulated universal motor with extremely high efficiency – unrivalled in robustness and effectiveness.
- Extremely powerful, motor with a compact design.
- Very stable clamping neck Ø 43 mm (standard) in steel design – for installation in drill rigs, CNC and router tables.
- Precision double ball bearings – for powerful and highly accurate routing.
- Tool holder with classic collets with clamping nut for optimum guidance of the tools and precise concentricity.
- Exact concentricity even under the heaviest loads – guarantees results and safety.
- Ideally suited for heavy routing operations in window construction, in the furniture industry, for dowel and profile milling, edge processing, etc.
- Design incl. tacho control electronics for constant working speeds for even cutting speeds, very quiet running, anti-lock protection, soft start for jerk-free Start-up, fast clocking and PTC thermal monitoring.
| Router motor Suhner type UAK 30 RF 1,050 Watt | |
|---|---|
| For router tables, CNC and other stationary routing machines | |
| Technical data | |
| Input power | 1,050 watts |
| Speed infinitely variable | 3,500 – 25,000 rpm |
| Torque | 0,3 Nm |
| Voltage | 230 Volt / 50/60 Hz |
| Collet chuck | 8 mm –> further collets 3 and 6 mm and imperial sizes available separately. |
| Weight | 2,7 kg |
| Cable length | 2.5 m |
