Description
| Backset | 1-1/2″ [28.6 mm] |
| Handing | EZ Reverse System – Flip from LH to RH in seconds |
| Case | Zinc Plated Steel lock body |
| Case Dimensions: | 7/8″ width x 6″ Length |
| Cylinder: | Accepts standard 1″ to 1-1/2″ Mortise Thumbturns and 1″ to 1-1/2″ Mortise Lock Cylinders with Adams Rite (A/R) cams.(Cylinder Not Included) |
| Latchbolt |
Latch 13mm chrome plated with delrin insert for quiet latching 1/2″ width x 1.0″ length x 1/2″ Throw |
| Auxiliary Linchpin | Steel. Deadlocks latch bolt to prevent “loiding” or case-knife entry. |
| Faceplate | Measures 1″ x 6-7/8″ [25.4 mm x 174.6 mm]. |
| Strike | Standard strike furnished for flat jamb where door closes flush or nearly flush. |
| Standard Package |
Individually boxed with strike plate, 2 faceplates, and mounting screws. Available in 25 Count Carton / Box Cylinders, paddles, handles available separately. |
