Description
The kit includes:
- KB-DF224 Wrap/Unwrap Bit (22-24 AWG)
- P-DF224 Replacement Sleeve Assembly (DFB224, 22-24 AWG)
Specifications
| Wrap Function |
Wrap, Unwrap |
|---|---|
| Wire Gauge |
22-24 AWG (0.65-0.50 mm) |
| Minimum Terminal Diagonal |
0.054″ (1.37 mm) |
| Maximum Terminal Diagonal |
0.073″ (1.85 mm) |
| Terminal Hole Depth |
0.50″ (12.70 mm) |
| Terminal Hole Diameter |
0.075″ (1.9 mm) |
| Effective Radius |
0.111″ (2.82 mm) |
| Wrap Post Size |
0.045″ (1.14 mm) |
| Dimensions | 5 in x 0.43 in x 0.51 in (12.7 cm x 1.09 cm x 1.3 cm) |
| Weight | 0.09 lb (40.86 g) |
| UPC # | 811490013902 |
Downloads:
- Spec Sheet
