Description
Updated robust design! Add these 52″ panel clamps to your JLT Clamping System and boost your production. The 100% steel construction is guaranteed to never twist, bow, or bend and comes with a lifetime warranty on all welded components.
The included mounting plates easily hang and slide into a JLT stationary rack—simply attach with a bolt over the 1/2″ sq. mounting blocks. Create and customize your glue up rack to your desired setup! The laser-cut, paddle-style jaw latch provides superior securement to the 1/4″-thick serrated drawbar.
Updated Features:
- Boxed tubular frame is more rigid over previous C-channel
- 1/4″-thick, vertically-oriented serrated drawbar
- Latch provides stronger securement to the drawbar
- One-piece welded clamp screw/drawbar assembly for more stability
- Minimum clamp opening as small as 5″
Also available in 40″ length.
Note: Cannot ship to Idaho, Montana, or Utah.
Features
- Each clamp can achieve up to 3,000 lbs. clamping force
- Patented Equalizer Design provides equal clamping from the front and rear jaws, resulting in a high quality panel
- Clamps mounted on a JLT Panel Clamp provide a flat, even surface to ensure better glue ups
- Jaws are toed in at a 1° angle to help hold boards in place
- 100% steel construction and a lifetime warranty on all welded components
Specs
Clamp length:52″
Jaw height:3-1/2″
Jaw width:4-5/8″
Min. clamp opening:5″
SKU: #812B-M1-3.5J-52L-H-R
