Description
Specifications:
| Function: | 01 – Passage – Latch Always Open |
| Construction: | Heavy-Duty wrought steel, zinc dichromate plated |
| Handing: | Field Reversible |
| Backset: | 2-3/4″ (70mm) |
| Door Thickness: | 1-3/4″ standard |
| C to C: | ℄ lever to ℄ cylinder is 3-7/8” (98mm) |
| Armor Faceplate: | Brass or Stainless Steel; 8” x 1-7/32” (203mm x 31.6mm); ANSI Standard A115.1 |
| Deadbolt: | 1”(25.4mm) throw; hardened stainless steel |
| Latchbolt: | 3/4”(19mm) throw; one-piece stainless steel with anti-friction reversible tongue |
| Auxiliary Latch: | Stainless steel, non-handed |
| Toggle button: | High rust-resistant chrome-plated zinc alloy |
| Trims: | LR01 Rose and Lever |
| Strike: | Brass or Stainless Steel; ANSI Standard A115.1; curve lip with dust box |
| Cylinder: | No Cylinder (NC) |
| Finishes: | 26D Satin Chrome |
| Grade: | Comply with ANSI/BHMA A156.13-2017 Grade 1 requirement |
Downloads:
- Product Overview
