HVS0401U – Overview

The AVMATRIX HVS0401Uis a 4-channel HDMI/DP multi-format video switcher with a compact and robust metal housing design for video switching, audio mixing and different conversion effects. The input signal is automatically detected, the PGM output is scalable and compatible with a wide range of devices for convenience and flexibility, and the USB output can be connected directly to a PC for video capture. This cost-effective switcher will be the perfect choice for your live streaming applications.

• Features:

  • USB Type-C for video capturing (UVC)
  • PIP function, adjustable size and position
  • Audio mixer: 3.5mm MIC/ RCA/ HDMI embedded audio
  • AUTO/ CUT transitions and MIX/ FADE/ WIPE effects
  • GPIO interface for live tally system
  • FTB for emergency situation

• Specifications:

  • Connection
  • Video In:
    – Inputs 1-3: 3xHDMI
    – Input 4: 1xHDMI & 1xDisplayPort
  • Video Out:
    – PGM: 2xHDMI
    – Multiview: 1xHDMI
    – USB Capture: 1xUSB-C
  • Audio In:
    – MIC/Line: 2x(3.5mm audio)
    – RCA: 1x(stereo audio)
  • Tally Out: 1xDB-15
  • Power In: 1xDC 12V IN
    Functions
  • Functions:
    – Image Still
    – Transitioin Speed
    – MUTE
    – Audio follows Video
    – Audio Mixer
  • Transitions:
    – AUTO
    – CUT
  • Effects:
    – WIPE
    – MIX
    – FADE
    – FTB
  • Layouts:
    – PIP
    – Multiview
    Video Format
  • HDMI In Format Support:
    – 1080p 60/59.94/50/30/29.97/25/24/23.98/23.976
    – 1080i 50/59.94/60
    – 720p 60/59.94/50/30/25/24
    – 576i 50, 576p 50, 480p 59.94/60, 480i 59.94/60
  • PC HDMI/DP Input Format Support: 2560×1600, 2048×1152, 1920×1080,1680×1050, 1600×1200, 1600×900, 1400×1050, 1440×900, 1366×768, 1360×768, 1280×1024, 1280×960, 1280×800, 1280×768, 1280×720, 1280×600, 1152×864, 1024×768, 800×600, 640×480
  • HDMI PGM Out:
    – 1080p 60/50/30/25/24
    – 1080i 60/50
  • HDMI Multiview Out: 1080p60
  • HDMI Color Space: RGB/YCbCr
  • USB Capture Out: MJPG , Up to 1080p60
    Others
  • Power: 12V, 1.5A, 18W
  • Dimension (LxWxD): 9.4″ x 5.5″ x 1.71″ (238.5mm x 140.4mm x 43.5mm)
  • Weight:
    – Net: 1.73lbs (785g)
    – Gross: 3.30lbs (1500g)
  • Operating Temperature: 14°F – 140°F (-20°C – 60°C)
  • Storage Temperature: -22°F – 155°F (-30°C – 70°C)

• Item Includes:

  • 1xPower supply (12V 2A)
  • 1xUSB cable (type A-C)
  • 1xTally connector (DB-15)

• GTIN:

  6971118001941
